NEW - LNS QUICK LOAD SERVO 65 Magazine Bar Loader
*Fixed or Sliding Headstock
a 5% surcharge may apply from LNS to cover additional expenses due to logistics during COVID
General Specifications As Per Brochure:
Base Unit
1/4” through 2-5/8” diameter x 63” length bar capacity (*)
• Three Pushers (6, 12 and 20 mm)
• 23” X-Axis or Y-Axis Retraction system
• Custom Electrical Cable Package with Plugs
TECHNICAL SPECIFICATIONS
Bar Diameter Capacity: ¼” to 2-5/8”
Overall Length: 78”
Bar Length Capacity: 12” to 63” (*)
Overall Width: 65”
Pusher Diameters: 6 mm, 12 mm, 20 mm
Control Voltage: 24V DC
Magazine Capacity: 24.8 linear inches
Operating Voltage: 200-480 volts, 60 HZ, 1 AMP
(*) Maximum bar length cannot exceed the combined length of the headstock/actuator assembly.
Bar straightness: For optimum performance recommended bar straightness is .5 mm (.020") per meter (3.25'),
per side, non- accumulative.
PRICE AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
NOTE: THE MAXIMUM BAR LENGTH CANNOT EXCEED THE COMBINED LENGTH OF THE
HEADSTOCK/ACUATOR ASSEMBLY.
Installation (USA) $3,150.00
Installation (Canada & Mexico) $3,450.00
OPTIONAL ACCESSORIES QUANTITY LIST PRICE
Extended Steel liner $530.00
Adapter Kit For Square Bar Stock $360.00
Dual Channel Safety Circuit Protection (DCS) $535.00
Extended Retraction Option 47” (1200mm) $1,340.00
STEEL SPINDLE LINERS – QLS 65 requires one spindle liner tube for each bar stock diameter
Steel price also includes extended style and 2-piece style liners
Quantity Round Quantity Hex / Square
Up to 3-1/8" Drawtube I.D. (round) $530.00 $585.00
Surcharge for Hardened Liner $350.00
Confirmation Ring $550.00
Coolant Collector Extension $760.00
Quick Change Adapter $580.00
Polyurethane Spindle Liners Round / Square / Custom
Up to 3-1/8” Drawtube I.D. (each) $ 375.00 / $510.00 / $960.00
