KSI TCM 32S CNC Swiss Lathe, New in 2018 | IH 605057

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.

General Specifications:
Bar Diameter: 1-1/4"
Chucking Diameter in Sub: 1-1/4"

Tool Layout
OD: 6
Front: 5
Back End: 4 (ER 16 / 2 Fixed, 2 Live)
Sub Tool: 3 (1 Fixed, 2 Live)

Main Drill/Tap
Drilling: 3/8"
Tapping: M8

Cross
Drilling: 0.31" (ER16)
Tapping: M6 (ER16)
Slotting: Width 0.059" x 1/8"

Back End
Drilling (Fixed): 3/8" (ER16)
Drilling (Live): 0.31" (ER16)
Tapping (Fixed): M8 (ER16)
Tapping (Live): M6 (ER16)

Main Spindle
Spindle Speed: 8,000 RPM
Spindle Motor: 10 HP

Sub Spindle
Spindle Speed: 8,000 RPM
Spindle Motor: 2.9 HP

Tool Speed (Cross & Back End): 5,000 RPM
Tool Motor: 1.34 HP

Machine Dimensions: 118" x 57" x 70"
Machine Weight: 7,716 lbs
