Hanwha XD26H CNC Swiss Lathe New 2014 | SB 7611473
ConditionUsed
1 available
Hanwha XD26H CNC Swiss Lathe, New 2014
FMB Turbo 3-26 Magazine Bar Loader, Full 12'
Fancu i-Series Control
FMB Turbo 3-26 / 12' Magazine Bar Loader (2-channel sets, to be confirmed)
All tooling, accessories available for this machine
High Pressure Coolant System w/ manifold
Misc Tooling:
3 position double sided live tool attachment for the main
4 live face tools for the sub.
The two deep drilling positions next to the sub spindle can also be driven.
To be Confirmed:
6-pos back tool unit - To be confirmed
I-bag 60K spindle
Tri-Mist 850Mist Collector
Saw Cutter
To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an
inspection of the machine(s) and accessories prior to purchase.
General Specifications:
Capacity: 1.00" (26MM)
Main Spindle Speed: 8,000 RPM
Sub Spindle Speed: 8,000 RPM
Sub Spindle Indexing: 1 degree
Cross Drill Speed: 8,000 RPM
Back working Live Tool Speed: 6,000 RPM
Rapid Traverse Rate: 1259 IPM
Feed Rate: 236 IPM
Main Spindle Motor: 2.99/7.5HP
Sub Spindle Motor: 2.04/2.99 HP
Cross Drill Motor: 3/4 / 1.49 HP
Max Drill/ Tap Main: 0.39" / M8
Max Turning Length: 8.26"
Power Consumption: 15KVA
Tooling: 21 total
-OD Turning Tools: 5
-Live Cross Tools: 4
-Y Axis ID Tool Block: 5
-Front ID Tools: 2 Live (off center drills by sub)
-Back working Tools: 4 Total, 2 fixed, 2 live (ALL CAN BE SET TO FIXED)
Machine Dimensions: 92.9 L" x 49" x 69"
Machine Weight: 7,500 Lbs
