OKUMA MULTUS B750-W/4000 CNC LATHE WITH 5 AXIS OR MORE | IH 7611790
ConditionUsed
1 available
OSP-P200L CNC control
Full B-axis Contouring
24" Main Spindle Chuck
24" Sub Spindle Chuck
80 capacity tool changer
Capto C8 spindle Taper
SMW Hydraulic Steady Rest
Chip Conveyor
1000 PSI High Pressure Coolant
Y-Axis Gauging
Y-Axis Off Center Cut Function
50" Long Boring Bar Change Over System
Auto Gauging System Renishaw
Renishaw RMP60
Super Big Bore A2-20 Nose
Auto Door
Turret Air Blow
Operator Platform
Multi-Tap Transformer
Three Color Tower Light
Spindle Chiller Unit
Remote Jog Handle
DISTANCE BETWEEN CENTERS:
178.90"
Max Turning Diameter:
41.34"
Max Swing:
41.34"
X-Axis Travel:
42.52"
Y-Axis Travel:
+/- 12.99"
Z-Axis Travel:
165.94"
W-Axis Travel:
133.66"
C-Axis Travel:
.001 degree
B-Axis Travel:
-30 to + 210 degree
B-Axis Index Angle:
.001 degree
Max Work Piece Length:
171"
Chuck Size Main/Sub:
24"
Spindle Bore:
10.75"
Spindle Milling and Turning:
50 HP
Spindle Taper:
Capto C8
Main and Sub Spindle Max RPM:
1,800
Max Spindle RPM:
5,000
Feed Rates:
1575 IPM
Spindle Nose:
A2-20
Tool Changer:
80
