2022 EUROTECH TROFEO B465-SY2 11AXIS CNC LATHE | JS 7611808
ConditionUsed
1 available
2022 EUROTECH TROFEO B465-SY2, 11-axis CNC lathe, excellent for precision tasks. Includes coolant systems, 8" chuck, 35 HP motor, 4,000 RPM, 2.75" bar capacity. Compact design with sturdy build at 16,314 lbs for efficient machining performance.
Accessories
One - Coolant through the Sub-Spindle with 200 mm ejection
One - Extended Parts Ejection
One - Jet Stream High Pressure Coolant System 1,000 PSI.
One-Multi-Tap Transformer for 400 Volts
One - Eurotech tool monitoring system
One - Coolant flush system
MACHINING CAPACITY
Maximum bar capacity.............................................2.75"
Maximum turning diameter.........................................8"
Maximum stroke Y-axis stroke (both)..............................3.8"
LOWER TURRET
Number of tool stations (main spindle)...........................12
Turret indexing time.............................................0.10 sec/pos.
Turret indexing type. Fanuc servo-driven bi-directional Slide stroke:
Z-axis...........................................................21.26"
X-axis...........................................................6.7"
MAIN SPINDLE
Draw-tube capacity...............................................2.75"
Spindle through bore capacity .................................3.03"
Spindle speed range (infinitely variable)........................4,000
Variable speed steps.............................................Direct drive
Spindle motor (Fanuc 22S)........................................35 HP
Motor type.......................................................S series
Spindle nose.................................................... A2-6
REVOLVING TOOL ATTACHMENT
UPPER/LOWER TURRET
Number of upper turret positions...............................max
Number of lower turret positions...............................max
Drive motor - maximum rating
(upper and lower turrets)......................................AC HP 5
Speed range (infinitely variable)..............................4000
Revolving tool axis............................................X, C, Z & Y
Y Axis Strokes (both)..........................................+1.97"/ -1.57"
SUB-SPINDLE
Drawtube capacity..............................................1.77"
Spindle through bore capacity..................................2.17"
Spindle speed range (infinitely variable)..................... 5,000
Spindle drive motor max. rating................................15 HP
Spindle nose...................................................A2-5
Slide movement - (B-axis).....................................NC control
Slide stroke - (B-axis).....................................26.37"
UPPER TURRET
Number of tool stations (main spindle).........................12
Turret indexing time...........................................0.10 sec/pos.
Turret indexing type................................Fanuc servo-driven bi-directional
Slide stroke:
Z-axis.........................................................24.8"
X-axis.........................................................6.7"
GENERAL INFORMATION
Voltage required...............................................400 volt AC, 3-phase
Air Supply.....................................................80 psi @ 4 CFM
Amperage Draw..................................................120 Amp.
MACHINE DIMENSIONS
Width..........................................................85.0"
Height.........................................................87.0"
Length with chip conveyor......................................179.0"
Machine weight with chip conveyor..............................16,314 lbs.
