Equipped with to be verified by buyer
OSP-P300SA(LP) Control
ATC 60, Capto C6 Spindle Taper
Tool Presetter
Parts Catcher
Chip Conveyor, Hinge Style, High 750
VR8 480V High Pressure Coolant Pump, MP Systems
MP Systems 1200 PSI Coolant Thru Spindle
MP 1200 480V Pump Mounted Mist Collector
| # Axis | 5 | 5 |
| Swing | 24.8" | 629.92 mm |
| Machining Length | 35.43" | 899.92 mm |
| Chuck Size | 6" | 152.4 mm |
| Bar Capacity | 2.59" | 65.786 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 5,000 RPM | 5,000 RPM |
| Turning Dia | 24.8" | 629.92 mm |
| Control | CNC (OSP-P300Sa) | CNC (OSP-P300Sa) |
| Dimensions | 142.52" X 87.01" X 101.66" | 142.52" X 87.01" X 101.66" |
| Weight | 17,820 LBS | 17,820 LBS |
SWING OVER SADDLE: 24.8"
DISTANCE BETWEEN CENTERS: 35.43"
X-AXIS TRAVEL: 22.83"
Y-AXIS TRAVEL: +/- 3.15"
Z-AXIS TRAVEL: 35.51"
W-AXIS TRAVEL: 39.37"
B-AXIS TRAVEL: 30 TO +195 DEGREE
B-AXIS INDEXING: 0.001 DEGREE
MAIN SPINDLE CHUCK SIZE: 10"
MAIN SPINDLE SPEED: 5,000 RPM
MAIN SPINDLE POWER: 30 HP
SPINDLE NOSE: A2-6
MAIN SPINDLE BORE: 2.59
MAIN SPINDLE BAR SIZE: 3.15"
SUB SPINDLE CHUCK SIZE: 8"
SUB SPINDLE SPEED: 6,000 RPM
SUB SPINDLE POWER: 15 HP
SUB SPINDLE BORE: 2.6"
SUB SPINDLE BAR SIZE: 3.15"
MILLING SPINDLE SPEED MAX: 12,000 RPM
MILLING SPINDLE TAPER: CAPTO C6
ATC CAPACITY: 60
MACHINE SIZE: 142.52" X 87.01" X 101.66"
MACHINE WEIGHT: 17,820 LBS
