2006 Citizen L20VIII CNC Swiss Lathe | IH 7612660

To the best of our knowledge all details listed below are deemed correct.
It is the buyer’s responsibility to confirm all details and we encourage an inspection of the machine(s) and
accessories prior to purchase.

General Specifications:

Machining Diameter: 0.812"
Machining Length per one Chuck: 8.1"
Drilling Diameter: Up to .394"
Spindle Speed: 200 - 10000 RPM
Main Spindle Indexing: 1 degree (C-axis option)

Back-work:
Chucking Diameter of Pick-off Spindle: .812"
Pick-off Spindle Speed: 200 - 8000 RPM
Pick-off Spindle Motor: 2 HP

Rotary Tool:
Rotary Spindle Speed: 200 - 5000 RPM
Rotary Tool Motor: .5 HP

Number of Tools Mounted: 16
OD / Front ID / Back ID / Live Tools: 6/3/3/4
Power Consumption: 6 Kva

Machine Dimensions: 65" x 37"
Machine Weight: 3900 lbs.
